Cisco Catalyst WS-C4500X-32SFP+ V06 – 32-Port 10G SFP+ Aggregation Switch

The Cisco Catalyst WS-C4500X-32SFP+ V06 is a high-performance, fixed-aggregation switch designed for enterprise campus networks. With 32 SFP+ ports supporting 10 Gigabit Ethernet, this switch delivers up to 800 Gbps of switching capacity, ensuring efficient and scalable network performance. Its compact 1U form factor and optional 8-port uplink module slot make it an ideal solution for space-constrained environments requiring high-density 10G connectivity.

Key Features:

• 32 x 10G SFP+ Ports: Provides high-density 10 Gigabit Ethernet connectivity for aggregation and core layers.

• Optional Uplink Module Slot: Supports an additional 8 x 10GE SFP+/SFP ports via the C4KX-NM-8SFP+ module (sold separately).

• High Performance: Delivers up to 800 Gbps switching capacity and up to 250 Mpps forwarding rate.

• Redundancy and Resiliency: Features dual hot-swappable power supply bays and five field-replaceable fans for high availability.

• Advanced Software Features: Runs on Cisco IOS XE Software, offering capabilities like Flexible NetFlow, Cisco TrustSec, and support for Virtual Switching System (VSS).

• Management Interfaces: Includes USB Type A and B ports, a 10/100/1000 Mbps management port, and a console port for versatile management options.

• Compact Design: 1U rack-mountable chassis suitable for space-constrained deployments.

Specifications:

• Model: WS-C4500X-32SFP+ V06

• Enclosure Type: Rack-mountable – 1U

• Switching Capacity: Up to 800 Gbps

• Forwarding Rate: Up to 250 Mpps

• Memory: 2 GB RAM

• Power Supply: Supports dual hot-swappable 750W AC or DC power supplies (sold separately)

• Cooling: Five field-replaceable fans with front-to-back airflow

• Management Ports: 1 x 10/100/1000 Mbps Ethernet, 1 x USB Type A, 1 x USB Type B, 1 x Console port

• Optional Modules: C4KX-NM-8SFP+ (8-Port 10GE Network Module)

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Relative Humidity: Up to 90% non-condensing
